SS304 SS316 SS316L M10 M16 DIN933 ISO4017 Stainless Steel full thread Hex Bolt
Hex bolt Definition
The head and the screw (with external thread of the cylinder) of two parts of fasteners, to cooperate with nuts, used for fastening the two parts with hole.
This kind of connection form according to bolt connection.Such as screw the nut on the bolt, can make the two parts separately, so the bolt connection is a detachable connection.
Stainless steel Hex Bolt Material and chemical composition
Stainless steel material including SS201, SS304,SS316, SS316L
material | Chemical Composition(%) | |||||||
C | Si | Mn | P | S | Ni | Cr | Mo | |
SS201 | ≤0.15 | ≤1 | 5.5~7.5 | ≤0.06 | ≤0.03 | 3.5~5.5 | 16~18 | |
SS304 | ≤0.08 | ≤1 | ≤2 | ≤0.045 | ≤0.03 | 8~10.5 | 18~20 | |
SS316 | ≤0.08 | ≤1 | ≤2 | ≤0.045 | ≤0.03 | 10~14 | 16~18 | 2~3 |
SS304L | ≤0.03 | ≤1 | ≤2 | ≤0.045 | ≤0.03 | 8~12 | 18~20 | |
SS316L | ≤0.03 | ≤1 | ≤2 | ≤0.045 | ≤0.03 | 10~14 | 16~18 | 2~3 |
SS410 | ≤0.15 | ≤1 | ≤1 | ≤0.04 | ≤0.03 | 11.5~13.5 |
Stainless steel Hex Bolt Manufacturer Method:
Hot rolled wire rod - dial (cold) - spheroidizing annealing (softening) - mechanical descaling - acid - cold dial - - thread processing - heat treatment - Test
Stainless steel Bolt Mechanical Property
Material | Mechanical Characteristics | |||
Reductin Of Area | Yield Point | Tensile Strength | Elongation | |
% | MPA | MPA | % | |
SS201 | ≥45 | ≥275 | ≥520 | 55~66 |
SS304 | ≥50 | ≥205 | ≥515 | ≥40 |
SS316 | ≥50 | ≥205 | ≥515 | ≥40 |
SS304L | ≥50 | ≥170 | ≥485 | ≥40 |
SS316L | ≥50 | ≥170 | ≥485 | ≥40 |
SS410 | ≥45 | ≥275 | ≥480 | ≥20 |
Stainless steel Hex Bolt Application:
Environmental protection equipment, medical equipment, communications equipment, electric power facilities, electronic products, food machinery, petrochemical industry, ship assembly, pump valve, pipe, building curtain wall, open places, etc.
DIN933 Hex Bolt Drawing
