M12 Carbon Steel Zinc Plate Gr 4.8 5.8 8.8 Eye Hook Screw

M12 Carbon Steel Zinc Plate Gr 4.8 5.8 8.8 Eye Hook Screw
Certification: ISO9001
Place Of Origin:zhwjiang,CHINA
MOQ: 1000pcs
Price: Negotiation
Payment Terms: L/C, , T/T, Western Union,Paypal
Supply Ability: 450tons Per Month

Quantity:
  • M12
  • HNF
  • 17181301
  • Zinc
  • M12
  • Steel
  • Lag Screw Eye Bolt
  • M4-M100

M12 Carbon Steel Zinc Plate Gr 4.8 5.8 8.8 Eye Hook Screw



As a standard fastener, the eyebolt is widely used in electromechanical products, and its main function is lifting load.


规格 单只垂直起吊 工作载荷极限(T) 单只侧向起吊 工作载荷极限(T)
M8 0.16 0.04
M10 0.25 0.06
M12 0.4 0.1
M16 0.63 0.16
M20 1 0.25
M24 1.6 0.4
M30 2.5 0.62
M36 4 1
M42 6.3 1.6
M48 8 2
M56 10 2.5
M64 18 4
M72 20 5
M80 25 6.25
M100 40 10

skills requirement
1. The eyebolt should be made of 20 or 25 steel

2. The eyebolts must be integrally forged. Forgings should be normalized and the scale removed. The grain size of the finished product should not be lower than Grade 5 (GB6394), and the forgings should not have excessive burnt and crack defects.

Generally, the surface treatment is not carried out, but according to the use requirements, galvanizing passivation, chrome plating and other surface treatments can be performed, and according to GB5267-85. Dehydrogenation should be carried out immediately after electroplating.

M12 Carbon Steel Zinc Plate Gr 4.8 5.8 8.8 Eye Hook Screw Drawing


DIN444 有眼螺栓
